Laboratory coating and laminating machine

Laboratory coating laminator

Equipment application field: This three-coating combined coating laminating machine is specially designed for product development and small batch proofing.

Equipment features:

1. Siemens system PLC centralized control;

2. Various precision coating methods can be selected (comma scraper coating, slit extrusion coating, microgravure coating, etc.);

3. Optional with a variety of heat sources for heating (electricity, natural gas hot blast stove, heat transfer oil, etc.);

4. The substrate unwinding is equipped with a stripping device, which can adapt to composite materials;

5. Double-roller composite structure, steel roller and rubber roller match;

6. High clean baking and drying oven, the maximum temperature is 160°C;

Main technical parameters:

1. Working width: 600 mm

2. Mechanical spokes: 700mm

3. Mechanical speed: 0.2~5 m/min, PLC automatic adjustment

4. Equipment size (L*W*H): 17000×2500×4000 mm

5. Heating power: 100KW adjustable

6. Total equipment power: 170KW

7. Power supply: 380V 50Hz

8. Total weight of equipment: 16000KG
